Image 3
MYIR | System-On-Modules (SOMs)

MYC-C8MMX-V2

The MYC-C8MMX-V2 is a powerful, low-cost ARM-based System-on-Module (SoM) featuring the NXP i.MX 8M Mini processor. With a quad-core ARM Cortex-A53 at 1.8GHz, a Cortex-M4 real-time processor at 400MHz, 2GB DDR4, 8GB eMMC, and 32MB QSPI Flash, this module offers excellent performance for industrial, consumer, and IoT applications. It supports Linux and Android OS, and is ideal for applications requiring rich media capabilities and high connectivity options..

  • Detail
  • Special Features
  • Specification

The MYC-C8MMX-V2 CPU Module is a high-performance SoM designed for demanding industrial, consumer, and IoT applications. Powered by the NXP i.MX 8M Mini processor, it features a quad-core ARM Cortex-A53 and a Cortex-M4 co-processor. It supports up to 4GB DDR4, 64GB eMMC storage, and 32MB QSPI Flash, enabling it to handle a variety of applications such as smart home systems, industrial control, and consumer electronics. The module provides robust media capabilities with 1080p VPU support, high-speed connectivity options including Gigabit Ethernet, and flexibility with GPIO and expansion interfaces. It supports Yocto Linux, Ubuntu, and Android, offering developers the tools needed for rapid prototyping and product development.

  • Processor:

    • NXP i.MX 8M Mini Processor

    • 1.8 GHz Quad-core ARM Cortex-A53

    • 400 MHz Cortex-M4 Real-time processor

    • 2D/3D GPU and 1080p VPU

  • Connectivity & Peripherals:

    • 1x 10/100/1000Mbps Ethernet

    • 2x USB 2.0 Host, 1x USB 2.0 OTG

    • 1x PCIe

    • 3x Serial ports, 3x I2C, 3x SPI

    • 5x I2S/SAI

    • 1x MIPI-CSI, 1x MIPI-DSI

    • Up to 103 GPIOs

  • Memory & Storage:

    • 2GB DDR4 (supports up to 4GB)

    • 8GB eMMC Flash (supports up to 64GB)

    • 32MB QSPI Flash

  • Temperature Range:

    • Commercial grade: 0°C to 70°C

    • Industrial grade: -40°C to 85°C

  • Power Supply:

    • 5V/0.23A

  • OS Support:

    • Yocto Linux 5.4.3

    • Ubuntu 18.04 (Linux Kernel 4.14.98)

    • Android 9.0.0

  • Processor:

    • NXP i.MX 8M Mini Processor

      • 1.8 GHz Quad-core ARM Cortex-A53

      • 400 MHz Cortex-M4

      • 2D/3D GPU and 1080p VPU

  • Memory:

    • 2GB DDR4 (upgradable to 4GB)

    • 8GB eMMC (upgradable to 64GB)

    • 32MB QSPI Flash

  • Connectivity:

    • 1x 10/100/1000Mbps Ethernet

    • 2x USB 2.0 Host

    • 1x USB 2.0 OTG

    • 1x PCIe

    • 3x Serial Ports

    • 3x I2C

    • 3x SPI

    • 1x MIPI-CSI, 1x MIPI-DSI

    • 5x I2S/SAI

    • Up to 103 GPIOs

  • Power Supply:

    • 5V/0.23A

  • Temperature Range:

    • Commercial grade: 0°C to 70°C

    • Industrial grade: -40°C to 85°C

  • OS Support:

    • Yocto Linux 5.4.3

    • Ubuntu 18.04 (Linux Kernel 4.14.98)

    • Android 9.0.0
