MYIR | System-On-Modules (SOMs)

MYC-J1028X CPU Module

The MYC-J1028X is a high-performance, compact System-on-Module (SoM) powered by the NXP Layerscape LS1028A processor. It integrates dual ARM Cortex-A72 cores running at 1.5 GHz and offers robust connectivity features with five Gigabit TSN Ethernet interfaces, PCIe 3.0, USB 3.0, and more. The module also includes 2GB DDR4 memory, 8GB eMMC storage, and supports extended operating temperatures from -40°C to 85°C. It’s ideal for industrial, automotive, and IoT applications, offering superior processing, networking, and display capabilities..

  • Detail
  • Special Features
  • Specification

The MYC-J1028X CPU Module is designed to support high-performance industrial and automotive applications. Powered by the NXP LS1028A processor, it delivers reliable, scalable, and cost-effective solutions for real-time networking, data acquisition, and processing. The module is equipped with various I/O interfaces such as Gigabit Ethernet, USB, PCIe, and more, which enable flexible integration into diverse systems. Its integrated GPU and display interfaces support media-rich applications, making it an ideal choice for smart homes, industrial HMIs, IoT, and energy management systems.

  1. Processor:

    • NXP Layerscape LS1028A

    • 1.5 GHz Dual-core ARM Cortex-A72

    • Integrated TSN Ethernet switches and controllers

    • Integrated GPU and LCD controller

  2. Memory:

    • 2GB DDR4 (supports up to 3GB/4GB)

    • 8GB eMMC (supports up to 16GB/32GB)

  3. Storage:

    • QSPI NAND Flash (optional)

    • XSPI NOR Flash (optional)

  4. I/O & Connectivity:

    • 5x Gigabit Ethernet

    • 2x USB 3.0

    • 2x PCIe 3.0

    • 2x CAN-FD

    • 1x SATA 3.0

    • 1x Display Port 1.3/eDP1.4 (up to 4K@60fps)

    • 1x JTAG, 6x SAI

  5. Temperature & Power:

    • Operating range: -40°C to 85°C (industrial grade)

    • Power supply: 5V/2A

  6. OS Support:

    • Ubuntu 18.04 (Linux 5.4.47)

    • Yocto3.2.1 Real-time Edge Image (Linux 5.10.9)

  • Processor:

    • NXP Layerscape LS1028A, Dual-core ARM Cortex-A72, 1.5 GHz

    • Integrated 3D GPU and LCD controller

  • Memory:

    • 2GB LPDDR4 (upgradable to 4GB)

    • 8GB eMMC (supports up to 32GB)

    • 32KB EEPROM

  • Storage:

    • Optional QSPI NAND Flash

    • Optional XSPI NOR Flash

  • I/O & Expansion:

    • 2x Gigabit Ethernet

    • 2x USB 3.0

    • 2x PCIe 3.0

    • 1x SATA 3.0

    • 1x MIPI-DSI, 1x LVDS, 1x RGB

    • 6x SAI, 8x UART, 8x I2C, 8x SPI, 2x CAN

  • Power Supply:

    • 5V/2A

  • Temperature Range:

    • -40°C to 85°C (industrial grade)

  • OS Support:

    • Linux (Ubuntu 18.04, Yocto3.2.1)
