MYIR | System-On-Modules (SOMs)

MYC-LR3568 System-On-Module

The MYC-LR3568 System-On-Module (SOM) offers exceptional performance and versatility for embedded projects. Powered by the Rockchip RK3568 processor, it features a quad-core ARM Cortex-A55 CPU, 1.0 TOPS Neural Processing Unit (NPU), and a Mali-G52 GPU. With up to 4GB of LPDDR4, 64GB of eMMC storage, and various expansion interfaces, it is perfect for applications like AIoT, industrial systems, and smart devices..

  • Detail
  • Special Features
  • Specification

The MYC-LR3568 System-On-Module (SoM) is designed for high-performance, low-power embedded systems. It integrates a Rockchip RK3568 processor with 4x Cortex-A55 cores and a Mali-G52 GPU, supporting 4K video decoding and encoding for high-quality multimedia applications. The NPU offers 1 TOPS of processing power for AI workloads. With options for 2GB or 4GB LPDDR4, and up to 64GB eMMC, the module supports a wide range of IoT and industrial applications. It provides extensive I/O through the 381-pin LGA interface, enabling additional customization and expansion through various peripherals. The MYC-LR3568 supports multiple OS platforms, including Linux and Debian, and offers advanced multimedia support with HDMI, LVDS, and MIPI-DSI interfaces.

  1. High-Performance Processor: Powered by the Rockchip RK3568 processor with quad-core ARM Cortex-A55 cores, providing up to 2.0GHz performance.

  2. Advanced Neural Processing Unit (NPU): Up to 1 TOPS for AI applications, enhancing processing power for machine learning and AI tasks.

  3. Video Decoding/Encoding: Supports 4K 60fps H.265/H.264/VP9 decoding and 1080P 60fps H.265/H.264 encoding for high-quality multimedia handling.

  4. Memory & Storage: Equipped with up to 4GB LPDDR4 and 64GB eMMC for efficient data processing and storage.

  5. Expansion Flexibility: Offers a 381-pin LGA expansion interface with extensive I/O options for further customization.

  6. Multi-OS Support: Compatible with Linux 5.10, Debian 11, providing flexibility for various development environments.

  7. Power Efficiency: Incorporates a Power Management IC (PMIC) for optimal power distribution and efficiency in industrial applications.

  • Processor: Rockchip RK3568, Quad-core ARM Cortex-A55, up to 2.0GHz

  • NPU: Up to 1 TOPS

  • GPU: Mali-G52 2EE

  • Memory: 2GB/4GB LPDDR4

  • Storage: 32GB/64GB eMMC, 32KB EEPROM

  • Expansion: 381-pin LGA expansion interface

  • Video Support: 4K 60fps H.265/H.264/VP9 decoding, 1080P 60fps H.264 encoding

  • I/O: Dual Gigabit Ethernet, USB 3.0/2.0, HDMI, LVDS, MIPI-CSI

  • Power Supply: 5V/3A

  • Working Temperature: 0°C ~ 70°C (commercial), -40°C ~ 85°C (industrial)

  • OS Support: Linux 5.10, Debian 11
