MYIR | System-On-Modules (SOMs)

MYC-LR3576 System-On-Module

The MYC-LR3576 SOM is powered by the Rockchip RK3576 processor, offering dual ARM Cortex-A72 and Cortex-A53 cores, a powerful NPU, and robust multimedia support with video decoding and encoding capabilities. With extensive connectivity options, this SOM is ideal for industrial IoT, AI, edge computing, and smart display applications..

  • Detail
  • Special Features
  • Specification

  • Processor:

    • Rockchip RK3576/RK3576J Octa-core ARM Cortex-A72 (2.2 GHz) and ARM Cortex-A53 (1.8 GHz)

    • ARM Mali-G52 MC3 GPU supporting OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1.

    • Neural Processing Unit (NPU) with up to 6 TOPS, designed for high-performance AI processing and inference.

  • Video Decoding/Encoding:

    • Supports H.265, VP9, AVS2, and AV1 video decoding up to 8K@30fps or 4K@120fps.

    • Capable of encoding 4K@60fps in H.265 and H.264 formats.

  • Memory and Storage:

    • Memory: 4GB/8GB LPDDR4X for efficient multitasking and high-speed processing.

    • Storage: 32GB/64GB eMMC storage with 32KB EEPROM for configuration and system data.

    • Expandable storage via TF card for additional space.

  • Connectivity Options:

    • USB: 1 x USB3.0, 2 x USB2.0, USB OTG

    • Ethernet: Dual Gigabit Ethernet ports for high-speed data transfer.

    • Expansion: PCIe slot for 4G/5G module and a 381-pin LGA expansion interface with extensive I/O support.

    • Display: MIPI-CSI for camera input, HDMI, MIPI-DSI, and LVDS output interfaces for display integration.

  • Operating Systems:

    • Linux 6.1, Debian 12, and Android 14 supported, offering a flexible software environment for various development needs.

  • Power and Temperature:

    • Power supply: 5V/3A, designed for low power consumption.

    • Operating temperature: -40°C ~ 85°C (for the RK3576J version).

  • High Performance Processor: Dual-core Cortex-A72 and Cortex-A53 cores, clocked up to 2.2 GHz and 1.8 GHz respectively, delivering robust processing power for demanding applications.

  • Integrated Neural Processing Unit (NPU): Up to 6 TOPS of AI acceleration, ideal for real-time inference and AI-based applications.

  • Versatile Video Support: Supports up to 8K video decoding at 30fps and 4K video at 120fps, perfect for high-definition multimedia processing.

  • Wide Connectivity Options: Includes Gigabit Ethernet, USB, PCIe, MIPI-CSI, MIPI-DSI, HDMI, LVDS, and more for seamless integration into a variety of systems.

  • Multiple Storage Options: 32GB/64GB eMMC and 32KB EEPROM with expandability via TF card slot.

  • Flexible OS Support: Compatible with Linux 6.1, Debian 12, and Android 14, offering a broad range of software options for development.

  • Processor: Rockchip RK3576/RK3576J Octa-core ARM Cortex-A72 (2.2 GHz) + ARM Cortex-A53 (1.8 GHz)

  • NPU: 6 TOPS

  • GPU: ARM Mali-G52 MC3, supports OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1

  • Memory: 4GB/8GB LPDDR4X

  • Storage: 32GB/64GB eMMC, 32KB EEPROM

  • Video: Up to 8K@30fps or 4K@120fps H.265/VP9/AVS2/AV1 video decoding, 4K@60fps H.265/H.264 video encoding

  • Peripherals: 381-pin LGA expansion interface

    • Interfaces: USB3.0, USB2.0, Gigabit Ethernet, CAN, MIPI-CSI, HDMI, MIPI-DSI, LVDS, TF card slot, PCIe, and more

  • Operating System Support: Linux 6.1, Debian 12, Android 14

  • Power Supply: 5V/3A

  • Dimensions: 43mm x 45mm

  • Working Temperature: -40°C ~ 85°C (with RK3576J CPU)
