MYIR | System-On-Modules (SOMs)

MYC-Y335X-V2

The MYC-Y335X-V2 is a compact, high-performance ARM System-On-Module (SOM) based on the TI AM335x series ARM Cortex-A8 processors. With up to 1GHz speed, 256MB DDR3, and 256MB NAND flash, it supports industrial applications with extended temperature operation from -40°C to +85°C. It also includes onboard Gigabit Ethernet PHY, power management IC, and a 146-pin expansion interface for flexible integration..

  • Detail
  • Special Features
  • Specification

The MYC-Y335X-V2 integrates the powerful TI AM335x processor family, featuring up to 1GHz of processing power with NEON SIMD Coprocessor, SGX530 graphics, and a programmable real-time unit subsystem. It supports a range of peripherals and offers flexibility with its expansion interface, allowing users to create custom embedded solutions. The module includes 256MB DDR3 SDRAM, 256MB NAND flash, and 32KB EEPROM, along with onboard Gigabit Ethernet PHY for fast communication. The power management is efficiently handled by the TPS65217C solution. The MYC-Y335X-V2 is ideal for applications requiring extended temperature operation, such as automotive, industrial control, smart lighting, and more.

  1. Processor: Up to 1GHz TI AM335x series ARM Cortex-A8 processors (AM3352, AM3354, AM3356, AM3357, AM3358, AM3359).

  2. Memory: 256MB DDR3 SDRAM (with compatibility for 128MB/512MB), 256MB NAND Flash (with compatibility for 128MB/512MB).

  3. Ethernet: On-board Gigabit Ethernet PHY for high-speed connectivity.

  4. Expansion Interface: 1.27mm pitch 146-pin stamp hole interface for I/O flexibility.

  5. Power Management: Features TI’s TPS65217C solution for efficient power handling.

  6. Operating System: Ready-to-run Linux 4.1.18 OS.

  7. Temperature Range: Extended temperature operation (-40 to +85°C), suitable for harsh industrial environments.

  8. Additional I/O: Includes up to 6x serial ports, USB 2.0 OTG, Gigabit Ethernet, I2C, SPI, ADC, and PWM.

  • Processor: Up to 1GHz TI AM335x ARM Cortex-A8 (AM3352, AM3354, AM3356, AM3357, AM3358, AM3359)

  • Memory:

    • 256MB DDR3 SDRAM (supports 128MB/512MB)

    • 256MB NAND Flash (supports 128MB/512MB)

    • 32KB EEPROM

  • Ethernet PHY: On-board Gigabit Ethernet PHY

  • Expansion Interface: 1.27mm pitch 146-pin stamp hole interface

  • Power Management IC: TI TPS65217C

  • OS Support: Linux 4.1.18

  • Temperature Range: -40 to +85°C (extended industrial grade)

  • I/O Signals:

    • 2x USB 2.0 OTG

    • Up to 6x Serial Ports

    • 2x Gigabit Ethernet

    • 2x I2C

    • 1x SPI

    • 8x ADC

    • 2x PWM

    • 2x SDIO
