MYIR | System-On-Modules (SOMs)

MYC-YG2LX CPU Module

The MYC-YG2LX CPU Module is a compact and high-performance System-on-Module (SoM) based on the RENESAS RZ/G2L processor. It features a 1.2GHz dual ARM Cortex-A55 and 200MHz Cortex-M33 cores, alongside 3D graphics, video codec support, and rich peripheral connectivity. This module supports 1GB/2GB DDR4, 8GB eMMC, and 32Kbit EEPROM, making it ideal for applications in human-machine interfaces (HMI), embedded devices, and industrial control systems. It operates on Linux 5.10 and Ubuntu 22.04 OS..

  • Detail
  • Special Features
  • Specification

The MYC-YG2LX CPU Module is built for versatility and efficiency in industrial and embedded applications. Powered by the RENESAS RZ/G2L processor, it features dual ARM Cortex-A55 cores with an additional Cortex-M33 MCU, providing strong processing power for applications that require video capabilities and AI functions. The Mali-G31 GPU supports 3D graphics, and the H.264 video codec enables smooth video playback and recording. The module includes onboard memory options up to 2GB DDR4, 8GB eMMC, and offers flexible expansion through its 164-pin Castellated-Hole and 58-pin LGA interfaces. Ideal for human-machine interface (HMI), embedded devices, and industrial control, the MYC-YG2LX is supported by Linux and Ubuntu operating systems, making it highly adaptable for various projects.

  • Processor: RENESAS RZ/G2L, Dual-core ARM Cortex-A55 @ 1.2GHz, Cortex-M33 @ 200MHz

  • Graphics and Video Codec: ARM Mali-G31 3D GPU, H.264 video decoding

  • Memory: 1GB/2GB DDR4, 8GB eMMC

  • Expansion Interface: 164-pin Castellated-Hole and 58-pin LGA interfaces

  • Connectivity: 2x Gigabit Ethernet, 2x USB 2.0 HOST, 1x USB 2.0 OTG

  • Power Management: RAA215300 PMIC

  • OS Support: Linux 5.10, Ubuntu 22.04

  • Processor: RENESAS RZ/G2L (1.2GHz Dual-core ARM Cortex-A55, 200MHz Cortex-M33)

  • Graphics: ARM Mali-G31 GPU

  • Memory: 1GB/2GB DDR4, 8GB eMMC

  • Storage: 8GB eMMC (optional 4GB, 16GB, 32GB)

  • Expansion: 164-pin Castellated-Hole, 58-pin LGA

  • Power Supply: 5V/1A

  • Power Management: RAA215300 PMIC

  • Operating Temperature: -40~85°C (industrial grade)

  • Operating Systems: Linux 5.10, Ubuntu 22.04
