MYIR | System-On-Modules (SOMs)

MYC-YT507H

The MYC-YT507H is a compact System-on-Module (SoM) powered by the Allwinner T507-H processor, featuring a quad-core ARM Cortex-A53 CPU at 1.5GHz, with a Mali-G31 GPU. It supports 1GB/2GB LPDDR4, 8GB eMMC, and includes a Power Management IC (PMIC). This SOM features a 381-pin LGA expansion interface for a wide range of peripheral connectivity and is suitable for applications such as industrial control, automotive electronics, and more..

  • Detail
  • Special Features
  • Specification

The MYC-YT507H is a high-performance, compact SOM based on the Allwinner T507-H processor with 1.5GHz quad-core ARM Cortex-A53 and a Mali-G31 GPU, designed for a variety of applications that require video decoding, AI, and robust connectivity. It offers options of 1GB/2GB LPDDR4 and 8GB eMMC storage, with a range of expansion possibilities via a 381-pin LGA package. The module supports high-definition video output including 4K, with multiple display interfaces such as HDMI, LVDS, and RGB. It also includes comprehensive connectivity options like Gigabit Ethernet, USB, UART, CAN, and more. The MYC-YT507H is ideal for applications in automotive electronics, industrial control, commercial displays, and smart terminals.

  1. Processor: Allwinner T507-H Quad-core ARM Cortex-A53 @ 1.5GHz, Mali-G31 MP2 GPU

  2. Neural Processing Unit (NPU): 2 TOPs for enhanced AI capabilities

  3. Memory: 1GB/2GB LPDDR4, 8GB eMMC

  4. Connectivity: 1x Gigabit Ethernet, 2x USB 2.0 Host, 1x USB 2.0 OTG, 6x UART, 2x CAN

  5. Display: Supports HDMI 2.0a (4K@60fps), LVDS, RGB, and CVBS output

  6. Expansion: 381-pin Castellated-Hole and 58-pin LGA interfaces for peripherals

  7. Power Management: Integrated Allwinner AXP853T Power Management IC

  8. Operating Systems: Supports Linux 4.9, Android 10, and Ubuntu 18.04

  • Processor: Allwinner T507-H Quad-core ARM Cortex-A53 @ 1.5GHz

  • Neural Processing Unit (NPU): 2 TOPs

  • GPU: Mali-G31 MP2

  • Memory: 1GB/2GB LPDDR4

  • Storage: 8GB eMMC

  • Expansion: 381-pin LGA and 58-pin interfaces

  • Power Supply: 5V/2A

  • Power Management: AXP853T Power Management IC

  • Operating Temperature: -40~85°C (Industrial grade)

  • Operating Systems: Linux 4.9, Android 10, Ubuntu 18.04
