Fluke | IR Visual

Fluke VT08 Visual IR Thermometer

The Fluke VT08 Visual IR Thermometer is a compact and rugged handheld tool that combines an infrared camera with a visible-light camera, offering visual thermal imaging alongside temperature measurements. It excels at quickly locating hot spots and diagnosing issues, with a temperature range of –20 °C to 400 °C (–4 °F to 752 °F) and built tough for industrial environments.

  • Detail
  • Special Features
  • Specification

The Fluke VT08 merges thermal and visual imagery for improved inspection efficiency. Its rugged design ensures durability in challenging environments, making it ideal for electrical, HVAC, and mechanical diagnostic work. A built-in laser pointer allows precise targeting, while its long battery life and quick charging ensure extended use. The device’s simple interface and thermal overlay capabilities enable seamless identification of hotspots and anomalies.

  • 120 × 90 Thermal Resolution: Provides over 10,000 infrared pixels for detailed thermal images.

  • IR–Visible Overlay & Picture-in-Picture (PIP): Enables seamless blending of thermal and visual images.

  • Wide Temperature Range: Measures temperatures from –20 °C to 400 °C.

  • Rugged Build: IP65 rated for dust and water resistance, and drop-tested to 2 m.

  • Laser Pointer: Enables precise targeting.

  • USB‑C Connectivity: Enables quick charging and data transfer.

  • Rechargeable Battery: Charges in under 2.5 h and provides over 5 h of run-time.

  • Easy Operation: Single-level menu design for quick navigation.

Specification Details
Infrared Resolution 120 × 90 pixels (~10,800 total)
Spectral Band 7.5–14 µm
Frame Rate 9 Hz
NETD < 60 mK
Field of View 50° × 37.5°
Spatial Resolution 7.6 mrad
Focus Fixed focus
Thermal Range –20 °C to 400 °C
Temperature Accuracy ±2 °C or 2% (23 °C ±5 °C)
Emissivity Adjustable
Display 2.4″ LCD
Storage ≥ 14 GB (earlier), ≥ 28 GB (later versions)
Battery Li‑ion (non-removable), ≥ 5 h run‑time
Charging Time < 2.5 h via USB‑C
Ingress Protection IP65 (with ports closed)
Drop Rating 2 m
Operating Temperature –10 °C to +50 °C
Weight ~0.36 kg
Dimensions (L×W×H) 204 × 66 × 76 mm
Warranty 1 year
