ANRITSU | Vector Network Analyzers

VNA Master + Spectrum Analyzer MS2036C

The VNA Master™ MS2036C is a rugged, handheld 2-port Vector Network Analyzer with integrated Spectrum Analyzer—offering frequency coverage from 5 kHz to 6 GHz (VNA) and 9 kHz to 9 GHz (Spectrum Analyzer). Designed for RF field engineers, it supports cable, antenna, interference, and general-purpose signal analysis in harsh environments like defense, aerospace, and wireless infrastructure maintenance..

  • Detail
  • Special Features
  • Specification

The MS2036C VNA Master offers a best-in-class combination of a 2-port, 2-path handheld Vector Network Analyzer and a powerful 9 GHz spectrum analyzer. Designed specifically for RF field engineers, this compact analyzer is the industry’s most versatile solution for S-parameter measurements, distance-to-fault testing, and signal diagnostics in aerospace, defense, and commercial communication systems.

With 5 kHz to 6 GHz VNA capability and 9 kHz to 9 GHz spectrum analysis, this instrument supports applications from cable testing to radome material analysis, filter tuning, and EM interference diagnostics. Featuring 12-term error correction and real-time 4-S-parameter display, it delivers bench-grade accuracy with unmatched portability.

On the spectrum side, features like Burst Detect™, up to 10 MHz RBW, and support for modulation demodulation (AM/FM/SSB) simplify troubleshooting and monitoring tasks. With Option 0431, engineers can conduct RF coverage mapping using internal GPS, while Option 0025 enables advanced interference hunting—especially when paired with the MA2700A InterferenceHunter™ for GPS-based triangulation.

This all-in-one tool is widely used for military systems, VOR antenna checks, aircraft/shipboard wiring diagnostics, and 5G network field testing. Its ruggedness and intuitive interface make it the go-to analyzer for critical field deployments.

  1. Dual Functionality – Combines a full-featured 2-port VNA and a wide-range spectrum analyzer in one compact device.

  2. VNA Coverage – 5 kHz to 6 GHz with 2-port, 2-path architecture and vector-corrected Distance-To-Fault.

  3. Spectrum Analyzer Range – 9 kHz to 9 GHz with Burst Detect™, 10 MHz RBW, and AM/FM/SSB demodulation.

  4. 12-Term Error Correction – Industry-first in a handheld VNA, delivering lab-grade accuracy in the field.

  5. Real-Time 4 S-Parameter Display – Single-connection S11, S21, S12, S22 via 3-receiver architecture.

  6. Coverage Mapping (Option 0431) – GPS-enabled RF mapping for indoor/outdoor validation and optimization.

  7. PIM Hunting & Interference Analysis – Optional PIM Hunter™ integration for tracking down rogue signals.

  8. Rugged & Portable – Engineered for field use with a compact, durable form factor and long battery life.

  9. Application-Specific Presets – One-button tests for field strength, ACPR, channel power, and C/I ratio.

  10. Secure Testing – No-compromise handheld tool for shipboard, airborne, or classified environments.

Parameter VNA Master (MS2036C) Specifications
VNA Frequency Range 5 kHz to 6 GHz
Spectrum Analyzer Range 9 kHz to 9 GHz
Number of Ports 2-Port, 2-Path
Measurement Speed 350 µs/point
S-Parameter Capability Real-time S11, S21, S12, S22 with 3-receiver architecture
Dynamic Range High (field-optimized, not specified numerically in source)
Error Correction 12-term error correction (handheld industry first)
Distance-To-Fault (DTF) Yes (VNA mode)
Demodulation AM, FM, SSB
Burst Detection Down to 200 µs
Coverage Mapping (Option 0431) Indoor/outdoor RF mapping with GPS tagging
Interference Analyzer (Option 0025) Yes – with MA2700A for GPS triangulation
Chassis & Portability Rugged handheld, field-ready
Applications Cable/antenna test, interference hunting, spectrum monitoring, 5G
