Revine MFR Products

RTPM6103

Rs. 21250.00

The RTPM6103 is a 60V 10A, 300W DC power supply with a standard USB interface and built-in multimeter functionality. It features a compact design, high-resolution output, and waveform editing for precise control in laboratory and field applications..

  • Detail
  • Special Features
  • Specification

The RTPM6103 offers a 60V output, adjustable from 0 to 60V, with 10A current capacity. The unit provides 150W/300W output power for reliable performance in a variety of applications. It supports precise control with high resolution of 10mV for voltage and 1mA for current adjustments. The USB communication interface supports SCPI for seamless integration with automated test systems. The built-in multimeter supports voltage, current, capacitance, resistance, continuity, and diode testing. Additionally, the power supply includes over-voltage and over-current protection, ensuring safe operation. The output voltage and current curve monitoring function offers real-time analysis of the power supply’s performance.



  • DC Power Supply with multimeter functionality

  • Compact design for easy portability

  • 2.8-inch TFT LCD display for easy output monitoring

  • USB communication interface supporting SCPI

  • 150W/300W output power with high resolution

  • Resolution: 10mV (voltage) / 1mA (current)

  • List waveform editing with 10 groups of editable timing output functions

  • Over-voltage and over-current protection for safe operation

  • Output voltage and current curve monitoring function

  • Multimeter Specifications:

    • 4 1/2 digits multimeter

    • Supports Voltage, Current, Capacitance, Resistance, Continuity, Diode Test

  • Product Name: RTPM6103: 60V 10Amps 300W DC Power Supply with Standard USB Interface

  • Output Voltage: 0 ~ 60V

  • Output Current: 0 ~ 10A

  • Output Power: 150W/300W

  • Resolution: 10mV (Voltage), 1mA (Current)

  • Display: 2.8-inch TFT LCD

  • Multimeter: 4 1/2 digits

  • Functionality: Voltage, Current, Capacitance, Resistance, Continuity, Diode Test

  • Waveform Editing: 10 groups of timing output functions

  • Protection: Over-voltage and over-current protection

  • USB Interface: SCPI support

  • Monitoring: Output voltage and current curve monitoring
