Spectrum Analyzers

Rigol DSA832E

Rs. 247623.00

The Rigol DSA832E is a high-quality spectrum analyzer with a frequency range of 9 kHz to 3.2 GHz and an ultra-low displayed average noise level of -148 dBm (typical). It features a 10 Hz minimum resolution bandwidth (RBW) and is designed for portable applications. With advanced digital IF technology, it ensures reliable performance and is perfect for RF applications in wireless communication, Wi-Fi, Bluetooth, and IoT. The device comes with an NABL Calibration Certificate and a 3-year warranty..

  • Detail
  • Special Features
  • Specification

The Rigol DSA832E offers exceptional performance in a compact and lightweight design. It utilizes digital IF technology, which provides improved accuracy and reliability for RF signal analysis, especially in complex and challenging environments. This analyzer’s 10 Hz minimum RBW allows for high-precision measurements, while its -148 dBm DANL ensures excellent sensitivity for low-power signals.

With its large 8-inch display and intuitive graphical user interface, the DSA832E is user-friendly and well-suited for both benchtop and field applications. The inclusion of auto features like Auto Tune, Auto Range, and Auto Scale makes signal acquisition simple and efficient, reducing the need for manual configuration.

The NABL calibration certificate guarantees the device meets the necessary accuracy standards, making it suitable for calibration and compliance testing in industries such as telecommunications, electronics, and broadcasting.

  • Frequency Range: 9 kHz – 3.2 GHz for versatile RF testing.

  • Minimum Displayed Average Noise Level (DANL): -148 dBm (typical) for high sensitivity.

  • Phase Noise: <-90 dBc/Hz at 10 kHz offset for excellent signal clarity.

  • Resolution Bandwidth (RBW): 10 Hz minimum for precise measurements.

  • Digital IF Technology: Provides reliable performance for demanding RF applications.

  • Large Display: 20.3 cm (8") TFT display, 800 × 480 pixels for easy viewing and quick adjustments.

  • Auto Functions: Auto Tune, Auto Range, Auto Scale, and Auto Couple for efficient signal acquisition.

  • User-Friendly Interface: Intuitive graphical interface with easy navigation and clear display of parameters.

  • Portable Design: Compact and lightweight, making it ideal for field applications.

  • NABL Calibration Certificate: Ensures measurement accuracy and compliance with industry standards.

  • 3-Year Warranty: Reliable support for peace of mind.

  • Frequency Range: 9 kHz to 3.2 GHz

  • Phase Noise: <-90 dBc/Hz at 10 kHz offset

  • Minimum Resolution Bandwidth (RBW): 10 Hz

  • Displayed Average Noise Level (DANL): -148 dBm (typical)

  • Display: 20.3 cm (8") TFT Color LCD, 800 × 480 resolution

  • Interfaces: USB-Host, USB-Device, LAN, GPIB

  • Dimensions: 410 mm × 224 mm × 135 mm

  • Weight: 4.65 kg

  • Warranty: 3 years

Model Overview

Model Max. Bandwidth EMI/QuasiPeak Advanced Measurement Kit Preamplifier Tracking Generator
DSA815 1.5 GHz Optional Optional Standard No
DSA815-TG 1.5 GHz Optional Optional Standard Yes
DSA832E 3.2 GHz Optional Optional Standard No
DSA832E-TG 3.2 GHz Optional Optional Standard Yes
DSA832 3.2 GHz Optional Optional Standard No
DSA832-TG 3.2 GHz Optional Optional Standard Yes
DSA875 7.5 GHz Optional Optional Standard No
DSA875-TG 7.5 GHz Optional Optional Standard Yes
