Spectrum Analyzers

Rigol DSA875

Now includes NABL Calibration Certificate.
Rs. 807120.00

The Rigol DSA875 is a high-performance spectrum analyzer with a frequency range from 9 kHz to 7.5 GHz. It includes a Tracking Generator and offers outstanding signal detection, achieving DANL as low as -161 dBm with a pre-amplifier. The analyzer features a large 8-inch display with 800×480 resolution, and advanced functions such as Auto Tune, Auto Range, and Auto Scale, making it ideal for both portable and benchtop RF applications. Now with an NABL Calibration Certificate and 3 years warranty..

Quantity:
- +
Product added to cart successfully
  • Detail
  • Special Features
  • Specification

🔧 Core Performance (Cause → Effect)

  • Digital IF inside → stable reads → fewer spurs, fewer false peaks.

  • DANL down to −161 dBm (with preamp) → weak signals appear → low SNR hunts get easier.

  • Phase and level hold steady → repeat runs match → decisions feel safe.

📡 Tracking & Tests (Task → Outcome)

  • Tracking Generator to 7.5 GHz → sweep filters, cables, and front-ends → map gain and match quickly.

  • System calibration → align paths end-to-end → cut guesswork.

  • Component checks → verify passbands and notches → spot drift early.

🖥 See It Clearly (Action → Result)

  • 8″ display → traces read at a glance → markers land accurately.

  • Clean menus + quick keys → fewer steps → faster answers.

🤖 Auto Helpers (Speed → Confidence)

  • Auto Tune / Auto Range / Auto Scale / Auto Couple → fast lock on targets → less knob work, fewer mistakes.

📜 Verified Accuracy (Trust → Compliance)

  • NABL calibration certificate → numbers you can cite → audit-ready reports.

🧳 Portable Build (Field → Lab)

  • Compact, lightweight frame → easy carry on site → easy fit on tight benches.

✨ Wide Frequency Reach
9 kHz → 7.5 GHz → one box, many bands → lab and field both covered.

🤫 High Sensitivity (DANL)
−135 to −161 dBm (typ.) → very low noise floor → weak signals stand out.

🧼 Clean Close-In View (Phase Noise)
−80 to −98 dBc/Hz @ 10 kHz → tighter skirts → more precise reads near carriers.

🎯 Amplitude Accuracy
<1.5 dB to <0.8 dB (nom.) → levels stay honest → comparisons hold up across bands.

🎚️ Fine Resolution (RBW)
10 Hz → 1 MHz → narrow for detail → wide for speed.

🔗 Tracking Generator
Sweeps to 7.5 GHz → align systems → test filters, cables, and components fast.

🖥️ Clear Display
8″ TFT, 800×480 → traces read easily → menus feel simple.

🤖 Auto Functions
Auto Tune / Range / Scale / Couple → quick lock → fewer knob turns.

🔌 Connectivity
USB / LAN / GPIB → move data easily → script and control remotely.

📜 Certified Accuracy
NABL calibration certificate → verified numbers → audit-ready reports.

🛡️ Warranty
3-year coverage → long-term reliability → lower ownership risk.

  • Frequency Range: 9 kHz – 7.5 GHz

  • DANL (Displayed Average Noise Level):

    • 9 kHz to 100 kHz: <-120 dBm (typ.)

    • 100 kHz to 5 MHz: <-135 dBm (typ.)

    • 5 MHz to 3.2 GHz: <-140 dBm (typ.)

    • 3.2 GHz to 6 GHz: <-136 dBm (typ.)

    • 6 GHz to 7.5 GHz: <-131 dBm (typ.)

    • With Preamplifier:

      • 9 kHz to 100 kHz: <-152 dBm (typ.)

      • 100 kHz to 5 MHz: <-152 dBm (typ.)

      • 5 MHz to 3.2 GHz: <-157 dBm (typ.)

      • 3.2 GHz to 6 GHz: <-153 dBm (typ.)

      • 6 GHz to 7.5 GHz: <-148 dBm (typ.)

  • Amplitude Range: DANL to +20 dBm

  • Max Input Voltage: 50 V

  • Sweep Time Range:

    • Span ≥ 100 Hz: 10 ms to 7500 s

    • Zero Span: 20 µs to 7500 s

  • Resolution Bandwidth (RBW): 10 Hz to 1 MHz (in 1-3-10 sequence)

  • Video Bandwidth (VBW): 1 Hz to 3 MHz (in 1-3-10 sequence)

  • Input Impedance: 50 Ohm nominal

  • Internal Frequency Reference: 10 MHz

  • Frequency Resolution: 1 Hz

  • Interfaces:

    • USB-Host for USB stick (for saving/loading waveforms)

    • USB for PC connection

    • LAN for network connection

    • GPIB (IEE-488) (optional with USB-GPIB module)

  • Dimensions: 362 mm × 179 mm × 128 mm (15.71" × 8.78" × 6.26")

  • Weight: 4.55 kg (10.03 lbs)

  • Warranty: 3 Years

  • Display: 20.3 cm (8") TFT-Color-LCD, 800 × 480 pixels

Model Overview

Model Max. Bandwidth EMI/QuasiPeak Advanced Measurement Kit Preamplifier Tracking Generator
DSA815 1.5 GHz Optional Optional Standard No
DSA815-TG 1.5 GHz Optional Optional Standard Yes
DSA832E 3.2 GHz Optional Optional Standard No
DSA832E-TG 3.2 GHz Optional Optional Standard Yes
DSA832 3.2 GHz Optional Optional Standard No
DSA832-TG 3.2 GHz Optional Optional Standard Yes
DSA875 7.5 GHz Optional Optional Standard No
DSA875-TG 7.5 GHz Optional Optional Standard Yes
