📡 Wide Frequency Reach
9 kHz → 7.5 GHz → one box, many bands → lab and field both covered.
🤫 High Sensitivity (DANL)
−135 to −161 dBm (typ.) → very low noise floor → weak signals stand out.
🧼 Clean Close-In View (Phase Noise)
−80 to −98 dBc/Hz @ 10 kHz → tighter skirts → precise reads near carriers.
🎯 Amplitude Accuracy
<1.5 dB to <0.8 dB (nom.) → levels stay honest → comparisons hold up across bands.
🎚️ Fine Resolution (RBW)
Min RBW 100 Hz or 10 Hz (model/option) → narrow for detail → wide for speed.
🔗 Tracking Generator
Sweeps to 7.5 GHz → align systems → test filters, cables, and components quickly.
🧠 Digital IF Engine
Stable architecture → fewer spurs → repeatable measurements in tough RF scenes.
🖥️ Large, Clear Display
8″ TFT (800×480) → traces read easily → menus feel simple → fewer missteps.
🤖 Auto Helpers
Auto Tune / Range / Scale / Couple → quick lock on signals → less knob work, faster answers.
🖱️ User-Friendly Interface
Intuitive graphics + quick keys → set parameters fast → adjust without hunting.
📜 Certified Accuracy
NABL calibration certificate → verified numbers → audit-ready reports.
🛡️ Warranty
3-year coverage → long-term reliability → lower ownership risk.
🧰 Helpful Tools (Task → Outcome)
-
Spectrum compare → overlay traces → spot changes quickly.
-
10 Hz RBW → ultra-fine detail on narrow signals.
-
AM demodulation → view/listen to depth → confirm modulation fast.
-
Peak table → list and sort top tones → read levels at a glance.
-
EMI measurement (option) → quasi-peak + CISPR filters → pre-compliance checks before the lab.
