The Rigol RSA5000 series spectrum analyzers are equipped with advanced real-time spectrum analysis capabilities, making them ideal for monitoring and characterizing complex RF systems such as WiFi, Bluetooth, and other wireless technologies. With real-time bandwidth of 25 MHz (upgradable to 40 MHz), users can capture signals with rapid changes in frequency, including frequency hopping signals and interference patterns that are common in modern communication systems.
One of the standout features of the RSA5000 is its 100% POI (Probability of Intercept) at 7.45 µs, ensuring that no signal is overlooked, even in high-speed, time-varying environments. The frequency-mask-trigger and the ability to visualize and isolate signals over amplitude, frequency, and time offer engineers a comprehensive tool for both RF testing and signal analysis.
The EMI filter and detector, including options like 9 kHz, 120 kHz, and 1 MHz, are standard, making the RSA5000 particularly suitable for EMI pre-compliance testing. Additionally, the analyzer's ability to set RBW as low as 1 Hz ensures highly detailed measurements, while the tracking generator adds flexibility for VSWR measurements.
For those working with embedded systems, the RSA5000 can cross-trigger and analyze IC2, SPI, and other bus signals alongside RF signals, offering a versatile solution for system designers.
