Waveform Generators

Rigol DG1022

Now includes NABL Calibration Certificate.
Rs. 58056.00

High quality 2 channel function / arbitrary waveform generator with 20 MHz bandwidth, 100 MSa/s and 4 kpts memory. Now includes NABL Calibration Certificate. 3 years warranty.

Quantity:
- +
Product added to cart successfully
  • Detail
  • Special Features
  • Specification

The Rigol DG1022 is a versatile Function and Arbitrary Waveform Generator, ideal for professionals involved in electronics development, R&D, or testing applications. The 20 MHz sine wave is just one of many waveforms this device can generate, ensuring that a wide range of signal tests can be performed with high accuracy.

In addition to signal generation, the 200 MHz frequency counter provides valuable measurements, making it useful in scenarios requiring high-precision timing and frequency testing. The USB interfaces further enhance the device's capabilities, allowing it to connect seamlessly with other devices for remote control, data storage, or PC-based analysis.

The graphical user interface ensures that the device is not only powerful but also easy to operate, even for those with minimal experience with waveform generators. The intuitive navigation reduces setup time, allowing engineers and technicians to focus on their tasks.

N/A

Feature Rigol DG1022
Channels 2
Max Frequency 20 MHz (Sine wave)
Frequency Counter 200 MHz
Waveform Types Sine, Square, Triangle, Ramp, Pulse, Arbitrary
USB Interfaces USB Host, USB Device
Display Graphical Interface
Output Amplitude 10 Vpp < 50 MHz
Waveform Memory Depth Not specified
Sample Rate Not specified
Size Compact, Benchtop

The Rigol DG1022 is a high-quality, cost-effective solution for signal generation, perfect for testing, development, and educational purposes. It offers robust functionality with ease of use, making it an essential tool for any electronics lab.
