Rigol DG1022A

Now includes NABL Calibration Certificate.
Rs. 83721.00

The Rigol DG1022A is a 2-channel Function/Arbitrary Waveform Generator capable of generating high-quality signals up to 25 MHz (Sine). It features two analog outputs, a 200 MHz frequency counter, and USB Host and USB Device interfaces. Designed for ease of use, it provides an intuitive graphical interface for quick function selection and parameter adjustments, making it ideal for various testing and signal generation applications..

Quantity:
- +
Product added to cart successfully
  • Detail
  • Special Features
  • Specification

The Rigol DG1022A is designed for generating both standard and arbitrary waveforms in a wide range of applications, including signal testing, frequency analysis, research and development, and educational purposes. With a frequency range of up to 25 MHz (sine), it provides high-quality, stable signals for a variety of tasks.

The 200 MHz frequency counter ensures precise measurements for signal verification, a critical feature for engineers working with high-frequency circuits. The device's USB connectivity (Host and Device) expands its functionality, allowing for easier integration with PCs for remote operation and data transfer.

Its graphical interface and intuitive menu system make it easy to navigate, reducing setup times and simplifying operations for users of all skill levels. The Rigol DG1022A is an essential tool for engineers needing an affordable, yet powerful, waveform generator with intuitive controls.

  • Dual-Channel Output:

    • Offers 2 independent analog channels for generating and testing signals in different configurations.

  • High-Quality Signal Generation:

    • Capable of producing 25 MHz sine waves along with multiple waveform types including square, triangle, ramp, pulse, and arbitrary signals, suitable for both analog and digital applications.

  • Frequency Counter:

    • Includes a 200 MHz frequency counter for accurate measurement and verification of signals, ideal for frequency-related tests.

  • User-Friendly Interface:

    • Intuitive graphical interface with simple menu navigation makes setup and operation straightforward for both beginners and advanced users.

  • USB Connectivity:

    • USB Host and USB Device interfaces enable easy connection to PCs for remote control, data logging, or software integration.

  • Compact and Portable:

    • The compact design ensures efficient use of bench space, while being portable enough for fieldwork or lab settings.

Feature Rigol DG1022A
Channels 2
Max Frequency 25 MHz (Sine Wave)
Frequency Counter 200 MHz
Waveform Types Sine, Square, Triangle, Ramp, Pulse, Arbitrary
USB Interfaces USB Host, USB Device
Display Graphical Interface
Output Amplitude 10 Vpp < 50 MHz
Waveform Memory Depth Not specified
Sample Rate Not specified
Size Compact, Benchtop



The Rigol DG1022A is a versatile and cost-effective function/arbitrary waveform generator, perfect for a wide range of signal generation and testing tasks in both research and production environments. It offers reliable performance with an intuitive interface, making it a must-have tool for engineers and technicians.
