Waveform Generators

RIGOL DG800

Now includes NABL Calibration Certificate.
Rs. 56817.00

High-quality 2-channel function/arbitrary waveform generator with 35 MHz bandwidth, 125 MSa/s sample rate, and 2 Mpts memory (expandable to 8 Mpts). Includes NABL Calibration Certificate and 3 years warranty..

Quantity:
- +
Product added to cart successfully
  • Detail
  • Special Features
  • Specification

The RIGOL DG800 Series waveform generator is designed to deliver premium performance in a cost-effective package. With a 16-bit resolution, SiFi II point-to-point sampling technology, and 2 Mpts memory (expandable to 8 Mpts), this generator is ideal for academic use, prototyping, and R&D environments. The DG800 is engineered for reliability with a fanless design, ensuring quiet operation for laboratory and classroom environments.

Perfect for students and engineers alike, the DG800 Series provides a high-frequency range, intuitive controls, and superior waveform generation accuracy. Whether you need a low-cost option for standard waveform testing or a reliable function generator for more advanced applications, the DG800 delivers. Its simple-to-use touchscreen interface makes waveform adjustments intuitive and quick.

  • High Resolution – 16-bit vertical resolution for precise waveform generation and accurate signal output.

  • Compact & Efficient Design – Fanless operation for quieter, cooler performance with an intuitive touchscreen interface.

  • Expandable Memory – Comes with 2 Mpts standard memory, expandable up to 8 Mpts for more complex waveform storage.

  • Wide Frequency Range – Supports a frequency range up to 35 MHz, suitable for a wide variety of signal generation tasks.

  • Low-Cost Yet Powerful – Designed as an entry-level solution without compromising on functionality, perfect for students and engineers.

  • Frequency Counter – Up to 240 MHz frequency counter, enhancing its utility in frequency measurement and verification.

  • Affordable – Priced competitively for high-value performance at ₹56,817 (inclusive of GST).

  • Versatile Output – Provides 10 Vpp output for frequencies under 10 MHz, ideal for most common waveform needs.

Model: DG811, DG812, DG821, DG822, DG831, DG832

  • Max Frequency: 10 MHz (DG811, DG812), 25 MHz (DG821, DG822), 35 MHz (DG831, DG832)

  • Resolution: 1 µHz

  • Sample Rate: 125 MSa/s

  • Vertical Resolution: 16 bits

  • Max Amplitude: 10 Vpp (<10 MHz)

  • Frequency Counter: Up to 240 MHz

  • Channels: 1 (DG811, DG821, DG831), 2 (all other models)

  • Memory Depth: 2 Mpts (upgradable to 8 Mpts)

  • Warranty: 3 years

  • NABL Calibration Certificate: Included
